Cable Tray Forming Machine

Cable Tray Forming Machine is used to produce cable trays related to the electrical industry, and the finished products produced are trapezoidal trays and slotted trays. Commonly used in building photoelectric communication, machine room electrical, circuit, cable equipment and other fields.

Process Flow:

Hydraulic uncoiling—pinching feeding leveling— servo feeding & hydraulic punching — Cutting — Roll forming—Unloading

Main parameter

C/N Item Unit Parameters
1 Forming speed M/min 0-15
2 Number of forming passes channels 20
3 Rolling thickness mm 1-2.5
4 Roll material Gcr15 quenching treatment
5 Shaft material 40Cr quenching treatment (HB220-260)
6 Shaft diameter Φ85mm, quenching treatment (Harbin bearing)
7 Cutting method Hydraulic shear
